APC BY SCHNEIDER ELECTRIC

APC SMX1500RM2UC uninterruptible power supply (UPS) Line-Interactive 1.44 kVA 1200 W 8 AC outlet(s)

Part number SMX1500RM2UC

SMART-UPS X 1500VA RACK/TOWER LCD 120V W/ SMARTCONNECT

  • Line-Interactive
  • 1.44 kVA 1200 W
  • Waveform: Sine
  • 8 AC outlet(s)
  • Sealed Lead Acid (VRLA)
  • Rackmount/Tower Black
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
SMX1500RM2UC
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware

Overview

Avoids costly power problems by keeping your IT equipment and data safe and available

Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems

Smarter productivity with ability to tailor to your specific application needs

Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds and notifications.

Save time with easy and convenient remote accessibility

Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities.

Peace of mind that comes with full equipment compatibility and reliability of a leader

Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management

Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Dynamic battery replacement date indicator and automatic self tests insure battery reliability and warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.

Specifications

Features
UPS topologyLine-Interactive
Output power capacity1.44 kVA
Output power1200 W
WaveformSine
Input operation voltage (min)75 V
Input operation voltage (max)154 V
Input frequency50/60 Hz
Output operation voltage (max)120 V
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Maximum current12 A
Surge energy rating645 J
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)5%
Noise level40 dB
Power protection featuresShort circuit
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm
Auto-restartYes
Ports & interfaces
AC outlet typesNEMA 5-15R
Power plugNEMA 5-15P
AC outlets quantity8 AC outlet(s)
USB portYes
USB 2.0 ports quantity1
USB port typeUSB Type-B
Serial interfaceYes
Serial interface typeRS-232
SmartSlotYes
Battery
Battery technologySealed Lead Acid (VRLA)
Number of batteries supported1
Battery life (max)5 year(s)
Battery recharge time3 h
Hot-swap batteryYes
Automatic battery testYes
Design
Form factorRackmount/Tower
Rack capacity2U
Cable length2.44 m
Product colourBlack
Display typeLCD
LED indicatorsYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m
Certificates
Compliance certificatesRoHS
CertificationcUL Listed, TAA compliance, UL 1778
Sustainability
Sustainability certificatesENERGY STAR
Weight & dimensions
Width432 mm
Depth490 mm
Height89 mm
Weight24.8 kg
Packaging data
Package width589 mm
Package depth620 mm
Package height246 mm
Package weight30 kg
Logistics data
Harmonized System (HS) code85078000

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
