Overview
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Specifications
Features
| UPS topology | Line-Interactive |
|---|
| Output power capacity | 1 kVA |
|---|
| Output power | 900 W |
|---|
| Waveform | Sine |
|---|
| Input operation voltage (min) | 82 V |
|---|
| Input operation voltage (max) | 143 V |
|---|
| Input frequency | 50/60 Hz |
|---|
| Output operation voltage (min) | 120 V |
|---|
| Output operation voltage (max) | 120 V |
|---|
| Maximum current | 12 A |
|---|
| Surge energy rating | 600 J |
|---|
| Noise level | 40 dB |
|---|
| Audible alarm(s) | Yes |
|---|
| Audible alarm modes | Low battery alarm, Overload alarm |
|---|
Ports & interfaces
| AC outlet types | NEMA 5-15R |
|---|
| AC outlets quantity | 8 AC outlet(s) |
|---|
| USB port | Yes |
|---|
| Serial ports quantity | 1 |
|---|
| Emergency Power Off (EPO) connector | Yes |
|---|
| SmartSlot | Yes |
|---|
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
|---|
| Battery recharge time | 3 h |
|---|
| Replacement battery cartridge | CURK116-01-02 |
|---|
Design
| Form factor | Rackmount/Tower |
|---|
| Cable length | 2.4 m |
|---|
| Product colour | Black |
|---|
| Display type | LCD |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -15 - 45 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3048 m |
|---|
| Non-operating altitude | 0 - 15240 m |
|---|
Weight & dimensions
| Width | 89 mm |
|---|
| Depth | 490 mm |
|---|
| Height | 432 mm |
|---|
| Weight | 22.9 kg |
|---|
Packaging data
| Package width | 246 mm |
|---|
| Package depth | 620 mm |
|---|
| Package height | 589 mm |
|---|
| Package weight | 27.3 kg |
|---|
