APC SMTL750RM2UCUS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 600 W 6 AC outlet(s)
Part number SMTL750RM2UCUS
APC SMART-UPS LITHIUM ION 750VA SHORT DEPTH RM 120V SMARTCONNECT TAA-COMPLIANT
Line-Interactive
0.75 kVA 600 W
Waveform: Sine
6 AC outlet(s)
Lithium-Ion (Li-Ion)
Rackmount Black, Silver
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
SMTL750RM2UCUS
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware
Overview
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive 2U short depth rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA5-15R outlets. This rackmount UPS is tower convertible with the mounting stabilizing feet (SMTL2USF sold separately). It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery The Smart-UPS is compliant with the Trade Agreements Act (TAA) requirements.
Specifications
Features
UPS topology
Line-Interactive
Output power capacity
0.75 kVA
Output power
600 W
Waveform
Sine
Input operation voltage (min)
75 V
Input operation voltage (max)
154 V
Input frequency
50/60 Hz
Output operation voltage (min)
120 V
Output operation voltage (max)
120 V
Output frequency
50/60 Hz
Maximum current
3.5 A
Surge energy rating
680 J
Heat dissipation
135 BTU/h
Output voltage Total Harmonic Distortion (THD)
5%
Noise level
41 dB
Ports & interfaces
AC outlet types
NEMA 5-15R
AC outlets quantity
6 AC outlet(s)
USB port
Yes
Serial interface
Yes
SmartConnect port
Yes
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery life (max)
10 year(s)
Battery recharge time
3 h
Design
Form factor
Rackmount
Rack capacity
2U
Cable length
2.4 m
Product colour
Black, Silver
Display type
LCD
International Protection (IP) code
IP20
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 35 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 7620 m
Certificates
Certification
NOM
Weight & dimensions
Width
438 mm
Depth
318 mm
Height
86 mm
Weight
15.4 kg
Packaging data
Package width
472 mm
Package depth
584 mm
Package height
229 mm
Package weight
17.7 kg
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
