APC SMTL3KRM2UCLNC uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 7 AC outlet(s)
Part number SMTL3KRM2UCLNC
SMART-UPS LITHIUM-ION 3000VA 120V W/ SMARTCONNECT PORT NETWORK
2880VA/2700W line interactive pure sine wave 2U rackmount UPS
Ideal for small edge environment, back office, network infrastructure and IDF/MDF closets
Lithium-ion battery minimizes the need to replace battery during the life time of UPS
Cloud-based remote power monitoring via SmartConnect Ethernet Port
1-Year Secure Network Management Card subscription included
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
SMTL3KRM2UCLNC
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware
Overview
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 2880VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA L5-30 input, 6 NEMA 5-20R and 1 NEMA L5-30R outlets. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery.
Specifications
Features
UPS topology
Line-Interactive
Output power capacity
3 kVA
Output power
2700 W
Waveform
Sine
Input operation voltage (min)
110 V
Input operation voltage (max)
125 V
Input frequency
50/60 Hz
Output operation voltage (min)
110 V
Output operation voltage (max)
125 V
Output frequency
50/60 Hz
Automatic Voltage Regulation (AVR)
Yes
Surge energy rating
459 J
Response time
6 ms
Heat dissipation
348 BTU/h
Number of input phases
1
Number of output phases
1
Crest factor
3:1
Emergency Power Off (EPO)
Yes
Output voltage Total Harmonic Distortion (THD)
5%
Noise level
55 dB
Audible alarm(s)
Yes
Audible alarm modes
Alarm when on battery, Low battery alarm
Ports & interfaces
AC outlet types
NEMA 5-20R, NEMA L5-30R
Power plug
NEMA L5-30P
AC outlets quantity
7 AC outlet(s)
USB port
Yes
Serial interface
Yes
SmartSlot
Yes
SmartConnect port
Yes
Battery
Battery technology
Lithium-Ion (Li-Ion)
Number of batteries included
1 pc(s)
Battery life (max)
10 year(s)
Battery recharge time
2 h
Hot-swap battery
Yes
Replacement battery cartridge
APCRBC174-LI
Design
Form factor
Rackmount
Rack capacity
2U
Cable length
2.4384 m
Product colour
Black
Display type
LCD
International Protection (IP) code
IP20
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 7620 m
Certificates
Compliance certificates
RoHS
Certification
CSA C22.2 NO. 107.3, FCC Part 15 Class A, NOM, UL 1778, UL 1973
Packaging content
Batteries included
Yes
Rack mount kit
Yes
Cables included
USB cable
Weight & dimensions
Width
432 mm
Depth
683 mm
Height
86 mm
Weight
34.2 kg
Packaging data
Package width
980 mm
Package depth
620 mm
Package height
254 mm
Package weight
42.7 kg
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
