Products › Power & Rack Equipment
APC BY SCHNEIDER ELECTRIC
APC SMTL3000RM2UCNC uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 8 AC outlet(s)
Part number SMTL3000RM2UCNC
APC SMART-UPS, LINE INTERACTIVE, 3KVA, LITHIUM-ION, RACKMOUNT 2U, 120V, 2X NEMA
- Line-Interactive
- 3 kVA 2700 W
- Waveform: Sine
- 8 AC outlet(s)
- Lithium-Ion (Li-Ion)
- Rackmount Black, Silver
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SMTL3000RM2UCNC
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Specifications
| UPS topology | Line-Interactive |
|---|---|
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Waveform | Sine |
| Input operation voltage (min) | 82 V |
| Input operation voltage (max) | 144 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 120 V |
| Output frequency | 50/60 Hz |
| Output voltage regulation | 5% |
| Surge energy rating | 459 J |
| Efficiency | 96% |
| Noise level | 55 dB |
| AC outlet types | NEMA 5–15R, NEMA 5–20R |
|---|---|
| AC outlets quantity | 8 AC outlet(s) |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RJ-45 |
| Ethernet LAN (RJ-45) ports | 1 |
| SmartSlot | Yes |
| Battery technology | Lithium-Ion (Li-Ion) |
|---|---|
| Typical backup time at full load | 4 min |
| Typical backup time at half load | 8 min |
| Form factor | Rackmount |
|---|---|
| Rack capacity | 2U |
| Product colour | Black, Silver |
| Display type | LCD |
| LED indicators | Yes |
| International Protection (IP) code | IP20 |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 7620 m |
| Certification | CSA C22.2 No 107.1, CULus, FCC part 15 class A, UL 1778, UL 1973 |
|---|
| Width | 432.1 mm |
|---|---|
| Depth | 683 mm |
| Height | 86.1 mm |
| Weight | 34.2 kg |
| Package width | 600 mm |
|---|---|
| Package depth | 980.4 mm |
| Package height | 254 mm |
| Package weight | 42.7 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
