APC SMTL1500RM3UCNC uninterruptible power supply (UPS) Line-Interactive 1.44 kVA 1350 W 6 AC outlet(s)
Part number SMTL1500RM3UCNC
SMART-UPS LITHIUM-ION SHORT DEPTH 1500VA 120V WITH SMARTCONNECT
Line-Interactive
1.44 kVA 1350 W
Waveform: Sine
6 AC outlet(s)
Lithium-Ion (Li-Ion)
Rackmount Stainless steel
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
SMTL1500RM3UCNC
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware
Overview
Description
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1500VA line interactive 3U short depth rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery.
Specifications
Features
UPS topology
Line-Interactive
Output power capacity
1.44 kVA
Output power
1350 W
Waveform
Sine
Input operation voltage (min)
120 V
Input operation voltage (max)
120 V
Input frequency
50/60 Hz
Output operation voltage (min)
120 V
Output operation voltage (max)
120 V
Output frequency
50/60 Hz
Automatic Voltage Regulation (AVR)
Yes
Surge energy rating
680 J
Response time
10 ms
Heat dissipation
135 BTU/h
Crest factor
3:1
Output voltage Total Harmonic Distortion (THD)
5%
EMI/RFI noise filtering
45 dB
Audible alarm(s)
Yes
Audible alarm modes
Alarm when on battery, Low battery alarm
Ports & interfaces
AC outlet types
NEMA 5-15R
Power plug
NEMA 5-15P
AC outlets quantity
6 AC outlet(s)
USB 2.0 ports quantity
3
USB port type
USB Type-A
Serial interface
Yes
Serial ports quantity
1
Ethernet LAN (RJ-45) ports
1
SmartSlot
Yes
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery life (max)
10 year(s)
Battery recharge time
3 h
Design
Form factor
Rackmount
Rack capacity
2U
Cable length
2.4 m
Product colour
Stainless steel
Display type
LCD
LED indicators
Yes
International Protection (IP) code
IP20
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 7620 m
Packaging content
Rack mount kit
Yes
Cables included
RJ-45, USB cable
Weight & dimensions
Width
438 mm
Depth
302 mm
Height
131 mm
Weight
19.5 kg
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
