APC IT Power Distribution Module 3x1 Pole 3 Wire 32A 3xIEC309 300cm, 360cm, 420cm
Part number PDM1332IEC-3P
IT POWER DISTRIBUTION MODULE 3X1POLE 3WIRE 32A 3XIEC309 300CM
- Power distribution module with three 1-pole breakers
- 32A breakers
- 300cm, 360cm, and 420cm output cables
- Warranty: 1 year
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- PDM1332IEC-3P
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
Factory assembled and tested Power Distribution Modules include circuit breaker, power cord, power connection, and circuit monitoring. Auto-detection of modules by the Modular PDU minimizes installation time.
Specifications
| Product colour | Black, Blue, Grey |
|---|
| Output connections | 3 x IEC 309 |
|---|
| Nominal input voltage | 400 V |
|---|---|
| Nominal output voltage | 230 V |
| Maximum input current per phase | 32 A |
| Maximum total current draw per phase | 32 A |
| Certification | CE, VDE |
|---|
| Width | 432 mm |
|---|---|
| Depth | 152 mm |
| Height | 152 mm |
| Weight | 6.39 kg |
| Package weight | 7.3 kg |
|---|---|
| Package width | 432 mm |
| Package depth | 152 mm |
| Package height | 152 mm |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
