Overview
Provides high definition surveillance with motion detection. 4MP HD camera support with video storage. Provides surveillance to help mitigate these risks through a wide array of cameras configuration, clip captures, configurable alerts and robust management options. Compatible with NetBotz 700 series appliances.
Specifications
Performance
| Type | IP security camera |
|---|
| Placement supported | Indoor & outdoor |
|---|
| Connectivity technology | Wired |
|---|
| Certification | CE; FCC 47 CFR Part 15 Class A, ICES-003 Class A, AS/NZS CISPR 22, VCCI Class A, Low Voltage
Directive 2014/35/EC, EMC Directive 2014/30/EC, RoHS Directive 2011/65/EU |
|---|
Design
| Form factor | Cube |
|---|
| Product colour | Black |
|---|
Camera
| Minimum illumination | 0.01 lx |
|---|
| Field of view (FOV) angle | 100° |
|---|
Image sensor
| Number of sensors | 1 |
|---|
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
|---|
| Sensor type | CMOS |
|---|
Lens system
| Fixed focal length | 2.8 mm |
|---|
Night vision
| Night vision | Yes |
|---|
| LED type | IR |
|---|
Video
| Maximum resolution | 2688 x 1520 pixels |
|---|
Audio
| Built-in speaker(s) | Yes |
|---|
| Built-in microphone | Yes |
|---|
Network
| Wi-Fi | No |
|---|
| Bluetooth | No |
|---|
Power
| Power source type | PoE |
|---|
| Power consumption (Power over Ethernet (PoE)) | 5.24 W |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 45 °C |
|---|
| Storage temperature (T-T) | -15 - 65 °C |
|---|
| Operating relative humidity (H-H) | 10 - 90% |
|---|
| Storage relative humidity (H-H) | 10 - 90% |
|---|
Weight & dimensions
| Width | 56 mm |
|---|
| Depth | 38 mm |
|---|
| Height | 97 mm |
|---|
| Weight | 120 g |
|---|
Packaging data
| Package width | 159 mm |
|---|
| Package depth | 96 mm |
|---|
| Package height | 165 mm |
|---|
| Package weight | 500 g |
|---|
Packaging content
| Number of cameras | 1 |
|---|
Logistics data
| Harmonized System (HS) code | 85258900 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
