APC GVSUPS40KR0B5GS uninterruptible power supply (UPS) 40 kVA 40000 W
Part number GVSUPS40KR0B5GS
GALAXY VS UPS 40KW 480V WITH N+ GALAXY VS UPS 40KW 480V WITH N+1 PO
Up to 99% efficient in eConversion mode
Maximize availability with modular architecture
Live Swap: Third party verified module replacement with no scheduled downtime
Unlock resiliency and sustainability with access to EcoStruxure software
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
GVSUPS40KR0B5GS
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware
Overview
Highly efficient, easy-to-deploy 40 kW, 480 V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. This UPS is for up to 5 smart modular high capacity battery strings, but is supplied without batteries, so you can easily customize the battery runtime. Includes 5x8 start-up service and one additional power module for N+1 redundancy.
Specifications
Features
Output power capacity
40 kVA
Output power
40000 W
Waveform
Sine
Input operation voltage (min)
408 V
Input operation voltage (max)
552 V
Input frequency
40 - 70 Hz
Output operation voltage (min)
480 V
Output frequency
50/60 Hz
Maximum current
60 A
Heat dissipation
4728 BTU/h
Crest factor
2.5:1
Noise level
54 dB
Battery
Battery technology
Sealed Lead Acid (VRLA)
Battery voltage
480 V
Design
Product colour
White
International Protection (IP) code
IP20
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
10 - 80%
Operating altitude
0 - 1000 m
Weight & dimensions
Width
550 mm
Depth
847 mm
Height
1970 mm
Weight
296 kg
Packaging data
Package width
1010 mm
Package depth
755 mm
Package height
2082 mm
Package weight
250 kg
Logistics data
Warranty period
1 year(s)
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
