APC Galaxy VM 160 kVA UPS Single 400-400 V with Backfeed protection, Start up 5x8
Part number GVMSB160KHS
GALAXY VM 160 KVA UPS SINGLE 400-400 V WITH BACKFEED PROTECTION, START UP 5X8
- Double-conversion (Online)
- 16 kVA 144000 W
- Waveform: Sine
- Tower White
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- GVMSB160KHS
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
GVMSB160KHS Features
Galaxy VM 160 kVA UPS Single 400-400 V with Backfeed protection, Start up 5x8
Highly compact, energy efficient 3-phase UPS for data center, facility and industrial applications. to be used with external battery cabinets.
Includes: Built-in modbus protocol adapter, Dust filter, Installation guide, Integrated network management, Seismic compliance, Top and bottom cable entry
Specifications
| UPS topology | Double-conversion (Online) |
|---|---|
| Output power capacity | 16 kVA |
| Output power | 144000 W |
| Waveform | Sine |
| Input operation voltage (min) | 250 V |
| Input operation voltage (max) | 600 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 Hz |
| Maximum current | 262 A |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Input power factor | 1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Input current Total Harmonic Distortion (THD) | 3% |
| Noise level | 65 dB |
| Power protection features | Overload |
| Audible alarm(s) | Yes |
| AC outlet types | Hard Wire 3-wire (3PH + G) |
|---|---|
| Serial interface | Yes |
| Serial interface type | RS-485 |
| SmartSlot | Yes |
| Form factor | Tower |
|---|---|
| Housing material | Steel |
| Product colour | White |
| Display type | LCD |
| LED indicators | Yes |
| International Protection (IP) code | IP20 |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -25 - 55 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 1000 m |
| Non-operating altitude | 0 - 14763 m |
| Certification | C-tick, CE, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IBC 2012 and CBC2013 to Sds=2.02g , ISTA 2B, OSHPD, RCM, UL 1778 |
|---|
| Quick installation guide | Yes |
|---|
| Sustainability certificates | ENERGY STAR |
|---|
| Width | 1052 mm |
|---|---|
| Depth | 854 mm |
| Height | 1970 mm |
| Weight | 699 kg |
| Package width | 1490 mm |
|---|---|
| Package depth | 1052 mm |
| Package height | 2156 mm |
| Package weight | 744.5 kg |
| Harmonized System (HS) code | 85078000 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
