Products › Power & Rack Equipment
APC BY SCHNEIDER ELECTRIC
APC Galaxy VM 160 kVA UPS Parallel 400-400 V with Backfeed protection, Start up 5x8
Part number GVMPB160KHS
GALAXY VM 160 KVA UPS PARALLEL 400-400 V WITH BACKFEED PROTECTION, START UP 5X8
- Double-conversion (Online)
- 160 kVA 144000 W
- Waveform: Sine
- 2 AC outlet(s)
- 480 V
- Tower White
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- GVMPB160KHS
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Specifications
| UPS topology | Double-conversion (Online) |
|---|---|
| Output power capacity | 160 kVA |
| Output power | 144000 W |
| Waveform | Sine |
| Input operation voltage (min) | 250 V |
| Input operation voltage (max) | 600 V |
| Input frequency | 40 - 70 Hz |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 Hz |
| Maximum current | 262 A |
| Input power factor | 1 |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Noise level | 65 dB |
| Audible alarm(s) | Yes |
| Web-based management | Yes |
| AC outlet types | Hard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G) |
|---|---|
| Power plug | Terminal |
| AC outlets quantity | 2 AC outlet(s) |
| Emergency Power Off (EPO) connector | Yes |
| SmartSlot | Yes |
| Battery voltage | 480 V |
|---|
| Form factor | Tower |
|---|---|
| Product colour | White |
| Display type | LCD |
| LED indicators | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -25 - 55 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 1000 m |
| Non-operating altitude | 0 - 14763.6 m |
| Certification | C-Tick, CE, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IBC 2012 and CBC2013 to Sds=2.02g, OSHPD, RCM, UL 1778, VFI-SS-111 |
|---|
| Sustainability certificates | ENERGY STAR |
|---|
| Width | 1052 mm |
|---|---|
| Depth | 854 mm |
| Height | 1970 mm |
| Weight | 699 kg |
| Package width | 1490 mm |
|---|---|
| Package depth | 1060 mm |
| Package height | 2156 mm |
| Package weight | 744.5 kg |
| Harmonized System (HS) code | 85078000 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
