Overview
Reliable and flexible DC power solutions for customer premise broadband, low power wireless and other telecommunication applications.
Specifications
Features
| Output power capacity | 0.027 kVA |
|---|
| Output power | 27 W |
|---|
| Input operation voltage (min) | 87 V |
|---|
| Input operation voltage (max) | 264 V |
|---|
| Input frequency | 47/70 Hz |
|---|
| Output operation voltage (max) | 13 V |
|---|
| Surge protection | Yes |
|---|
| Power protection features | Over current |
|---|
| Audible alarm(s) | Yes |
|---|
| Auto-restart | Yes |
|---|
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
|---|
| Battery capacity | 7.2 Ah |
|---|
| Battery voltage | 12 V |
|---|
| Hot-swap battery | Yes |
|---|
| Automatic battery test | Yes |
|---|
Design
| Form factor | Wallmount |
|---|
| Cable length | 2.4 m |
|---|
| Product colour | Beige |
|---|
| LED indicators | Battery replacement, Status |
|---|
Operational conditions
| Operating temperature (T-T) | -20 - 50 °C |
|---|
| Storage temperature (T-T) | -20 - 50 °C |
|---|
| Operating relative humidity (H-H) | 5 - 95% |
|---|
| Storage relative humidity (H-H) | 5 - 95% |
|---|
| Operating altitude | 0 - 3048 m |
|---|
| Non-operating altitude | 0 - 15240 m |
|---|
Certificates
| Compliance certificates | RoHS |
|---|
| Certification | cUL, FCC (Class B), CE, C-Tick |
|---|
Packaging content
| Manual | Yes |
|---|
Sustainability
| Sustainability compliance | Yes |
|---|
Weight & dimensions
| Width | 241 mm |
|---|
| Depth | 76 mm |
|---|
| Height | 190 mm |
|---|
| Weight | 3.41 kg |
|---|
Packaging data
| Package width | 343 mm |
|---|
| Package depth | 114 mm |
|---|
| Package height | 343 mm |
|---|
| Package weight | 4.09 kg |
|---|
Logistics data
| Products per pallet | 90 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
