Products › Power & Rack Equipment
APC BY SCHNEIDER ELECTRIC
APC BV400XU uninterruptible power supply (UPS) 0.4 kVA 220 W
Part number BV400XU
BACK-UPS 400VA, FLEXIBLE MOUNTING, LOW PROFILE, INDUSTRIAL
- 0.4 kVA 220 W
- Waveform: Sine
- 78 Ah
- Compact Black
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- BV400XU
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Specifications
| Output power capacity | 0.4 kVA |
|---|---|
| Output power | 220 W |
| Waveform | Sine |
| Input operation voltage (min) | 92 V |
| Input operation voltage (max) | 139 V |
| Input frequency | 50/60 Hz |
| Output frequency | 50/60 Hz |
| Output frequency regulation | 5 Hz |
| Surge energy rating | 300 J |
| Response time | 6 ms |
| Surge protection | Yes |
| Battery capacity | 78 Ah |
|---|---|
| Battery life (max) | 5 year(s) |
| Battery recharge time | 8 h |
| Form factor | Compact |
|---|---|
| Product colour | Black |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 15240 m |
| Width | 170 mm |
|---|---|
| Depth | 258 mm |
| Height | 62 mm |
| Weight | 4 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
