Products › Power & Rack Equipment
APC NetShelter SX, Server Rack Enclosure, 45U, White, 2124H x 750W x 1200D mm
Part number AR3355W
NETSHELTER SX 45U 750MM WIDE X 1200MM
- Maximum weight capacity: 1363.64 kg
- 45U
- Mounting type: Floor
- Material: Steel
- Locking
- IP20
- Removable side panels
- White
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- AR3355W
- Condition
- New
- Category
- Power & Rack Equipment › Rack Equipment
- 1GPA category
- Hardware
Overview
Feature-rich rack enclosure optimized for easy installation, managing cables, integrating power distribution, and maximizing airflow.
- Half-height side panels and option with brush strips for pass-through
- Quick release doors
- Perforated front door with curved profile
- Simple Selection
- Equipment mounting rails integrate with patch cabling systems
- Enclosure adjustment tools and hardware provided
- Easily removable cable access roof
- Cable access openings with pre-installed brushes
- Eyebolt support integrated into enclosure frame
- Split rear doors
- Integrated joining hardware with multiple width enclosure alignment
- Special packaging options for shipping rack with equipment mounted
Specifications
| Rack capacity | 45U |
|---|---|
| Maximum weight capacity | 1363.64 kg |
| Mounting type | Floor |
| Material | Steel |
| Product colour | White |
| Removable side panels | Yes |
| Locking | Yes |
| Locking type | Key |
| International Protection (IP) code | IP20 |
| Compliance certificates | RoHS |
| Width | 750 mm |
|---|---|
| Depth | 1200 mm |
| Height | 2124 mm |
| Weight | 169 kg |
| Side panels included | Yes |
|---|---|
| Manual | Yes |
| Package dimensions (WxDxH) | 2240 x 850 x 1334 mm |
|---|---|
| Package weight | 188.4 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
