APC BY SCHNEIDER ELECTRIC

APC Step down Transformer 10KVA power distribution unit (PDU) Black

Part number APTF10KT01

STEP DOWN TRANSFORMER APC 208V/120V 10KVA CUST PAYS FRT

Overview

Rack-Mountable

Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.

Transformer for Step-down or Step-up or Isolation

Step down transformer placed upstream of the UPS to avoid inrush current and saturation eliminating need to oversize transformer

Heavy duty design

The Vault Lock’s heavy duty hardened steel construction provides the highest degree of portable tampering protection available on the market.

Design
Product colour	Black

Ports & interfaces
Input connection type	Hard Wire 3-wire (2PH + G)
Output connections	1x Hard Wire 3-wire (2PH + G) 1x Hard Wire 4-wire (2PH + N +G) 2x NEMA L14-30R 2x NEMA L5-20R

Power
Nominal input voltage	208 V
Load capacity	10000 VA
Maximum input current per phase	60 A
Maximum total current draw per phase	60 A

Certificates
Certification	C-tick,CE,CSA,GOST,UL Listed,VDE

Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
