Overview
Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
Specifications
Design
| PDU types | Basic |
|---|
| Type | Single-phase |
|---|
| Rack capacity | 0U/1U |
|---|
| Mounting | Horizontal/Vertical |
|---|
| Product colour | Black |
|---|
Ports & interfaces
| AC outlets quantity | 12 AC outlet(s) |
|---|
| Power plug | C20 coupler |
|---|
| AC outlet types | C13 coupler |
|---|
| Input connection type | IEC-320 C20 |
|---|
| Output connections | (12) IEC 320 C13 |
|---|
Features
| Cable length | 2.5 m |
|---|
Power
| Load capacity | 3680 VA |
|---|
| Maximum input current per phase | 16 A |
|---|
| Maximum power | 3680 W |
|---|
Certificates
| Certification | cUL Listed,CE,CSA,GOST,Queensland Australia,UL 60950,UL Listed,VDE |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 45 °C |
|---|
| Storage temperature (T-T) | -25 - 65 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
Weight & dimensions
| Width | 447 mm |
|---|
| Depth | 57.2 mm |
|---|
| Height | 44.5 mm |
|---|
| Weight | 2.05 kg |
|---|
Packaging data
| Package weight | 3.64 kg |
|---|
| Package width | 464 mm |
|---|
| Package depth | 229 mm |
|---|
| Package height | 70 mm |
|---|
Logistics data
| Total carbon footprint (kg of CO2e) | 55.19 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
