Products › Power & Rack Equipment
APC BY SCHNEIDER ELECTRIC
APC NetShelter Basic Rack PDU, Zero U, 12.5kW, 208V, 30 C13 and 6 C19 outlet, 3ft input Cord
Part number AP7568
RACK PDU BASIC ZEROU 12.5KW 208V (30)C13 (6)C19 3 CORD
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- AP7568
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
-Includes: Cord retention bracket(s), Documentation CD, Installation guide, Rack Mounting brackets, Toolless Mounting Kit.
-Multi-branch power input.
-Toolless mounting capability.
-Vertical mounting capability.
Specifications
| Product colour | Black |
|---|
| Input connection type | Hubbell CS8365C |
|---|---|
| Output connections | -(30) IEC 320 C13. -(6) IEC 320 C19. |
| Cable length | 0.91 m |
|---|
| Nominal input voltage | 208 V |
|---|---|
| Nominal output voltage | 208 V |
| Load capacity | 12500 VA |
| Maximum input current per phase | 35 A |
| Maximum total current draw per phase | 35 A |
| Certification | cUL,CSA C22.2 No. 60950-1-03,UL 60950-1,UL |
|---|
| Operating temperature (T-T) | -5 - 45 °C |
|---|---|
| Storage temperature (T-T) | -25 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 56 mm |
|---|---|
| Depth | 89 mm |
| Height | 1778 mm |
| Weight | 6.95 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
