APC AP6037A power distribution unit (PDU) 3 AC outlet(s) 0U/1U Black
Part number AP6037A
RACK PDU BASIC 0U/1U 208V 8.6KW 3 C19
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- AP6037A
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 17.3kW using a single branch whip.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Specifications
| PDU types | Basic |
|---|---|
| Type | Three-phase |
| Rack capacity | 0U/1U |
| Mounting | Horizontal/Vertical |
| Product colour | Black |
| AC outlets quantity | 3 AC outlet(s) |
|---|---|
| Power plug | NEMA L15-30P |
| AC outlet types | C19 coupler |
| Cable length | 3.65 m |
|---|
| Nominal input voltage | 200-240 V |
|---|---|
| AC input frequency | 50/60 Hz |
| Maximum current | 30 A |
| Output voltage | 200-240 V |
| Load capacity | 8600 VA |
| Power protection features | Over current |
| Compliance certificates | RoHS |
|---|---|
| Certification | UL/C-UL, PSE |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -15 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Width | 388.1 mm |
|---|---|
| Depth | 125.7 mm |
| Height | 43.6 mm |
| Weight | 3.06 kg |
| Package weight | 5.06 kg |
|---|---|
| Package width | 454.9 mm |
| Package depth | 331.9 mm |
| Package height | 195 mm |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
