Overview
The AT-CV5001AC is a hot swappable power supply module for the AT-CV5001 18 slot Converteon chassis. Up to 2 power supply modules can be installed in the chassis to provide resiliency and increase up time.
Specifications
Power
| Total power | 140 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Input current | 3 A |
|---|
Performance
| Power supply unit (PSU) form factor | 2U |
|---|
| Mean time between failures (MTBF) | 64000 h |
|---|
Design
| Product colour | Grey |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -25 - 70 °C |
|---|
| Operating relative humidity (H-H) | 5 - 90% |
|---|
| Storage relative humidity (H-H) | 5 - 95% |
|---|
| Operating temperature (T-T) | 32 - 104 °F |
|---|
Certificates
| Certification | FCC A, EN55022 A, VCCI A, C-Tick, CE |
|---|
Safety regulation & standards
| Safety | UL60950-1 (cULUS), EN60950-1 (TUV) |
|---|
Weight & dimensions
| Weight | 1.72 kg |
|---|
Other features
| Dimensions (WxDxH) | 191 x 191 x 67 mm |
|---|
| Operating altitude | 0 - 3048 m |
|---|
| Power supply type | AC |
|---|
| Weight (imperial) | 1.72 kg (3.8 lbs) |
|---|
| Electromagnetic immunity | EN55024 |
|---|
